Triton
The comfortable
The Triton is the most comfortable among the B+B multifunctional wheelchairs. With its ergonomically shaped seat and backrest shell, the Triton adapts to the patient‘s contours. The adjustable side pads and knee pads provide additional comfort and hold. The adjustable seat width, seat depth and backrest height as well as the height-adjustable legrests with manual length compensation make the Triton individually adaptable. Already as standard, the Triton offers in addition a wide range of equipment that makes sitting even more comfortable: a 3 times adjustable headrest, heightand depth-adjustable side parts and adjustable seat and backrest angles.
Total weight
from 38,7 kg (Var.1)
from 40,2 kg (Var.2)
Total width
680 mm (Var.1)
730 mm (Var.2)
Total length
1040 mm
Total height
900 – 1200 mm
User weight
125 kg
AUSSTATTUNG
TIRES
Puncture-proof tires
Rear wheels 24″
Front wheels 7″
Quick release axle
SITZEINHEIT
Steel frame
Steel cross brace, side panel tubes, leg support tube
Seat depth adjustable
Anatomically shaped seat cushion
Knee ana calf pads adjustable
Backrest height adjustment
Comfort Backrest
Seat & back incontinence cover
Three-way adjustable headrest
side parts adjustable in height, removable and depth-adjustable
padded armrests
Leg rests angle-adjustable with length compensation, can be swiveled outwards and removed
Adjustable footplate angle
Heel strap
Calf pad
SONSTIGES
push handles adjustable in height
Knee lever brake
Anti-tip rollers
passive lighting
TECHNICAL DATA
| Triton |
|
|---|---|
| Seat width (Var. 1) | 360 – 430 mm |
| Seat width (Var. 2) | 430 – 500 mm |
| Seat depth* | 420 – 480 mm |
| Seat height* | 520 mm |
| Backrest height* | 500 – 620 mm |
| Seat angle | 0° – 15° |
| Backrest angle | -3° – 43° |
| Total width (Var.1) | 680 mm |
| Total width (Var.2) | 730 mm |
| Total height | 900 -1200 mm |
| Total length with Legrest | 1040 mm |
| Total length without Legrest | 840 mm |
| Total weight (Var.1) | 38,7 kg |
| Total weight (Var.2) | 40,2 kg |
| User weight | 125 kg |
| Frame color | Anthracite |
| * without seat cushion |
OPTIONALES ZUBEHÖR
Drum brakes
Abduction wedge
Headrest extension
Safety belt
Therapy tray
Arm support (hemiplegic)
Multifunctional wheelchairs in comparsion
Total weight: 30,8 kg
Total width: SW + 190 mm
Total length: 1200 mm
Total height: 1020 mm
User weight: 130 kg
Total weight: 38,7 kg (Var.1) / 40,2 kg (Var.2)
Total width: 680 mm (Var.1) / 730 mm (Var.2)
Total length: 1040 mm
Total height: 900 – 1200 mm
User weight: 125 kg
Total weight: 25,4 kg
Total width: 700 mm
Total length: 1265 mm
Total height: 880 – 1330 mm
User weight: 120 kg
