Pyro Light XL

The all-around Performer for Heavyweights

The Pyro Light XL is the extra-sturdy version of the tried-and-true Pyro Light from Bischoff & Bischoff. It supports users weighing up to 170 kg while weighing only 18.6 kg itself. It thus combines the advantages of a lightweight wheelchair with the stability required for users with higher body weight.

Seat depth and backrest height can be individually adjusted. Side panels in desk and long versions, swiveling leg rests, and angle-adjustable footplates ensure a good fit for the user. An extensive range of accessories further expands its applications.

Customizable for greater seating comfort

The Pyro Light XL is available in seat widths ranging from 510 to 560 mm, offering ample space even for larger users. The seat depth can be adjusted between 440 and 460 mm. The seat height is 500 mm.

The backrest system, featuring a lumbar curve and adjustable backrest height, promotes an upright yet relaxed sitting posture. A seat angle of 2 to 4° provides additional support while seated. The leg rests accommodate lower leg lengths ranging from 410 to 490 mm.

Well-designed features for everyday use

The side panels can be used in either the desk or extended version. This allows you to get close to tables while still providing secure support when standing up or moving around. The leg rests can be swiveled away. The footplates are angle-adjustable, and heel straps provide additional support for the feet.

The 24-inch drive wheels with quick-release axles and the 7-inch steering wheels are equipped with puncture-proof tires, making them low-maintenance. Knee-lever brakes, a tilt-assistance feature, and passive lighting ensure safety.

Flexibility and Customization Options

Depending on your needs, the Pyro Light XL can be supplemented with numerous options. These include a drum brake, one-hand brake and one-hand operation, an XL safety belt, anti-tip casters, an adjustable backrest, and a headrest. Height-adjustable side panels and push handles are also available.

Horizontally adjustable leg rests, amputation leg rests, a therapy table, and holders for IVs and oxygen tanks expand the range of applications for special care situations.

Sturdy construction and easy to transport

The frame is made entirely of aluminum. A double cross-brace provides the necessary stability under heavy loads. When folded, the wheelchair is only 330 mm wide and fits neatly into a trunk or storage room.

Thanks to quick-release axles, the drive wheels can be removed quickly, making loading easier. The frame is silver in color.

The lightest XL wheelchair in the lineup

Among the XL wheelchairs from Bischoff & Bischoff, the Pyro Light XL is the lightest option. The S-Eco 300 XL weighs 22.8 kg with the same weight capacity of 170 kg, while the Pyro Light Optima XL weighs 21.6 kg. For users with even higher body weight, the Econ XXL is available with a weight capacity of up to 250 kg.

Total weight

18,6 kg

Total width

SW + 190 mm

Total length

1050 mm

Total height

940 mm

User weight

170 kg

EQUIPMENT

TIRES

  • Puncture-proof tires

  • Rear wheels 24″

  • Front wheels  7″

  • Quick release axle

SEAT UNIT

  • Aluminum Frame

  • Aluminum cross brace, side panel tubes, leg support tube

  • Duo sideparts (desk and long)

  • Legrests can be swiveled inwards and outwards and removeable

  • Foot plates angle-adjustable

  • Seat depth adjustable

  • Backrest system with lumbar curve

  • Backrest height adjustment

OTHERS

  • push handles

  • Knee lever brake

  • Double cross brace

  • Heel straps

  • Tipping aid

  • passive lighting

DOWNLOADS

Order forms, Instruction manuals & Brochures

Instruction manuals
Order forms
Brochures

TECHNICAL DATA

 PYRO LIGHT XL
Seat width 510 – 560 mm
Seat depth 440 – 460 mm
Seat height 500 mm
Backrest height 420 mm
Seat angle 2° – 4°
Backrest angle 7°
Lower leg length 410 – 490 mm
Total width SW + 190 mm
Total width folded 330 mm
Total height 940 mm
Total length with Legrests 105 mm
total length without Legrests 830 mm
Total weight 18,6 kg
User weight 170 kg
Frame color Silver

OPTIONAL EQUIPMENT

Drum brake

Single-hand brake (mechanical)

One hand drive

Safety belt XL

Anti tippers

Backrest strap system

Infusion- & Oxygen bottle holder

Brake lever extension

Legrest extention

Legrest elevating adjustable horizontally

Amputation leg supports

Seat cushion (50 mm)

Headrest

Stick holder

Spoke protection

Therapy tray

Footplate

push handles adjustable in height

Sideparts adjustable in height

Handrim cover

XL | XXL Products in comparison

  • Total weight: 22,8 kg

  • Total width: SW + 200 mm

  • Total length: 1010 mm

  • Total height: 935 mm

  • User weight: 170 kg

  • Total weight: 18,6 kg

  • Total width: SW + 190 mm

  • Total length: 1050 mm

  • Total height: 940 mm

  • User weight: 170 kg

  • Total weight: 21,6 kg

  • Total width: SW + 230 mm

  • Total length: 1080 mm

  • Total height: 850 – 950 mm

  • User weight: 170 kg

  • Total weight: 35,2 kg

  • Total width: SW + 220 mm

  • Total length: 1100 mm

  • Total heigth: 990 – 1060 mm

  • User weight: 250 kg
